Application:
1.Central air conditioning and centralized ventilation system pre-filtration
2.Large air compressor pre-filtration
3.Pre-filtration of local high efficiency filtration unit
4.High temperature resistant air filter with stainless steel frame and high temperature resistance 250-300 °C filtration efficiency
Features:
- Low resistance ,
- Long service life
- large air flow
Specifications:
Frame : Galvanized steel/Oxide aluminium
Medium : Synthetic fiber/metal mash
Grid material: galvanized mesh
Filter class: G3/G4/
Maximum final Pressure drop (Pa): 450pa
Maximum temperature:70
Maximum relative humidity:90%
Specifications size
Tips:customized according to customer specification and requirements.
| Efficiency Specification W*H*D(mm) | Rated Air Volume (m^3/h) | Initial Resistance (≤Pa) | Final Resistance (Pa) | Effective Filtration Area(m^2) | Filtration Efficiency |
| 592*592*46 | 630 | 50 | 250-300 | 0.97 | F5 |
| 592*592*46 | 630 | 65 | 250-300 | 0.97 | F6 |
| 592*592*46 | 630 | 80 | 300-400 | 0.97 | F7 |
| 592*592*46 | 630 | 105 | 300-400 | 0.97 | F8 |
| 592*592*46 | 630 | 120 | 400-450 | 0.97 | F9 |
| 287*592*46 | 330 | 50 | 250-300 | 0.52 | F5 |
| 287*592*46 | 330 | 65 | 250-300 | 0.52 | F6 |
| 287*592*46 | 330 | 80 | 300-400 | 0.52 | F7 |
| 287*592*46 | 330 | 105 | 300-400 | 0.52 | F8 |
| 287*592*46 | 330 | 120 | 400-450 | 0.52 | F9 |
FAQ
Q1: What's the MOQ?
A1: The MOQ is 5pcs.
Q2: Can I make other different size?
A2: Yes, custom size is available
Q3:Can you send samples?
A3: Yes, we can send you sample for evaluating, free or not depend on products.
Q4: What' s the payment terms can you accept?
A4: T/T, L/C, Western Union.
Q5: How about the shipment?
A5: By sea, by air or by express, according to Qty and your demand.
Q6: How long is the lead time?
A6: About 3-10 days.
Q7: Are you a factory or trading company?
A7: Surely professional factory, set design, manufacturing &sale in one, you can get best factory quote from us.
Q8: What information should I provide if inquiry your air filter?
A8: Size, efficiency, filter frame, media, application, type etc. So that we can offer you exact quote.
